Meshroom D
在小型机箱设计中引入新的视野 - Meshroom D，4 面覆盖着极细的 1.5 毫米全网状面板，促进了优化的通风，旨在容纳高端组件，并在 14.97 升的体积中，即使在最激烈的任务中也能释放出最佳性能。该机箱具有灵活的空间布置，是构建多功能性的大师，能够容纳高达 3.4 个插槽的全尺寸 GPU，以及高达 150 毫米的高度灵活的电源选项。它专为定制回路爱好者而设计，拥有双散热器和 DDC 泵的专用空间。Meshroom D 采用时尚的钢制外墙，将美学与功能相协调，提供适应性强的解决方案，可与任何工作空间相得益彰。
产品状态说明：
- 全新：产品从未使用过，处于全新状态。
- 良好：产品已使用，但保持良好状态，功能正常，外观无明显瑕疵。
- 可接受：产品有一定使用痕迹，可能存在轻微磨损，但不影响正常使用。
释放显卡性能
设计支持最大3.4插槽、325mm长度和136mm宽度的GPU。
更大的散热空间
支持最高142mm的CPU散热器高度
小体积 大兼容
最小化占地面积，释放最大潜力
支持MATX主板，并配有额外的延长支架，提供多样的安装配置。
为分体水冷做好准备
有240mm双散热器分体水冷设计，同时支持DDC泵
Power Button Relocation
To improve your building experience and product reliability, we have made some production optimizations to our Meshroom S and Meshroom D cases. During this transition, you may receive either Variant A (old) or Variant B (new), depending on the inventory batch.
All accessories are fully compatible between both versions and product functionality is unaffected.
Meshroom D Variant A
Meshroom D Variant B
We moved the power button to the front panel (Variant B group) for easier access and to ensure a consistent I/O layout across all Meshroom series.
Other Internal Enhancements (No visual differences between variants – for your reference only)
- Top Panel Reinforcement: Internal structure has been enhanced to reduce flexing during assembly or shipping.
- Footpad Height Adjustment (Meshroom D): Slight increase to improve airflow and surface grip.
Specifications
Expansion slots
3 slots
4.6 slots with expansion bracket
Front interface
Variant A: 1x USB 3.2 Gen 1 Type-C (10 Gbps), 2x USB 3.0 Type-A (5 Gbps)
Variant B: 1x USB 3.2 Gen 2 Type-C (20 Gbps), 1x USB 3.0 Type-A (5 Gbps), 1x Power button
Rear interface
Variant A: Power button
Variant B: N/A
Top and front panel
Fine mesh panels
Side panel
Fine mesh panels
Tool-less push-to-lock
Both side, top, and front panels
2.5" drive mounts
With SFX PSU: 5 × 2.5” SSD
With ATX PSU: 4 × 2.5” SSD
3.5" drive mounts
With SFX PSU: 3 × 3.5” HDD;
With ATX PSU: 2 × 3.5” HDD
Side fan mounts
Left side: 2x 120 / 140 mm (PSU right or top mounted)
Right side: 1x 80 / 92 mm
Front fan mounts
1x 120 / 140 mm (SFX PSU top mounted)
Rear fan mounts
1x 80 / 90 mm
Dust filters
Bottom
Compatibility
Motherboard compatibility
Mini ITX / Mini DTX / Micro-ATX (requires optional expansion bracket)
Power supply type
ATX / SFX-L / SFX
Power supply max length
150 mm (PSU mounted on left side);
140 mm (PSU mounted on right side);
130 mm (PSU mounted on top)
CPU cooler height
Max 142 mm tall with no side fan bracket installed
Max 138 mm tall with side fan bracket installed
GPU max length (ITX MB)
3-slot mode: 325 mm length x 140 mm height;
3.4-slot mode: 325 mm length x 136 mm height
GPU max length (MATX MB)
3-slot mode: 325 mm length x 140 mm height with expansion bracket;
4.6-slot mode: 325 mm length x 136 mm height with expansion bracket
Side water cooler
ITX MB: max 323 mm length x 144 mm width x 65 mm thick (radiator+fans);
MATX MB: max 279 mm length x 124 mm width x 65 mm thick (radiator+fans)
Bottom water cooler
ITX MB: max 326 mm length x 144 mm width x 45 mm thick (radiator+fans) allows 22 mm width GPU;
MATX MB: max 326 mm length x 124 mm width x 55 mm thick (radiator+fans) allows 37 mm width GPU
General
Case dimensions
Variant A: 363 x 167 x 254 mm / 14.29 x 6.57 x 10.01 inch
Variant B: 363 x 167 x 259 mm / 14.29 x 6.57 x 10.19 inch
Without feet: 363 x 167 x 247 mm / 14.29 x 6.57 x 9.72 inch
Package dimensions
435 x 195 x 315 mm / 17.13 x 7.68 x 12.4 inch
Net weight
Variant A: 2.85 kg / 6.3 lb
Variant B: 2.9 kg / 6.4 lb
Gross weight
Variant A: 3.4 kg / 7.5 lb
Variant B: 3.5 kg / 7.7 lb
Volume
Variant A: 15.4 liters / 14.96 liters without feet
Variant B: 15.7 liters / 14.96 liters without feet
Case material
SGCC powder coated steel, plastic, PVC filter
Package contents
Case, accessory box, user manual
Warranty
2 years
