PCIe 라이저 케이블

$84.99 USD

컴팩트한 ATX 시스템 구축

15L 이하의 소형 케이스에서도 고효율 시스템을 구현할 수 있는 Meshroom S용 ATX 마더보드와 호환됩니다.

다양한 길이, 다양한 구성

다양한 Meshroom S 구성을 위해 특별히 설계된 GPU 라이저 케이블로 궁극의 유연성을 경험하세요. 모든 조립에 완벽합니다.

With the suitable riser cable, Meshroom S supports the installation of ATX motherboard and ATX power supply. Effortlessly downsize from mid-tower to mini ITX case, saving space while ensuring flexibility and convenience.

Specifications

Cable width

57 mm

PCIe standard

PCIe Gen 4.0 / PCIe Gen 3.0

Cable and bracket color

Matte Black, black powder coated steel

Cable length

PCIe Gen 4.0: 145 mm, 175 mm, 270 mm, 385 mm, 440 mm;
PCIe Gen 3.0: 210 mm, 175 mm, 270 mm, 385 mm, 440 mm

PCIe length support ITX MB

With rear GPU installed:

145 mm (dual reverse), lowest position not available
270 mm (direct)

With horizontal SFF GPU installed:

210 mm (female reverse)
270 mm (direct)

PCIe length support ATX MB

With rear GPU installed:

385 mm (female reverse)
440 mm (female reverse)

With horizontal SFF GPU installed:

270 mm (direct)

PCIe length support MATX MB

With rear GPU installed:

385 mm (female reverse)

440 mm (female reverse)

With horizontal SFF GPU installed:

175 mm (direct)

270 mm (direct)

PCIe length support MATX/ATX MB with horizontal SFF GPU installed

Support MATX:

385 mm (female reverse)

440 mm (female reverse)

Support ATX:

440 mm (female reverse)

GPU max length in ITX build

With rear GPU installed:

145 mm (dual reverse): 332 mm length and 152 mm width in 4 slots (82mm)
270 mm (direct): 353 mm length and 152 mm width in 4 slots (82mm) with extra feet

With horizontal SFF GPU installed:

210 mm (female reverse) and 270 mm (direct): 212 mm length in 3 slots (61 mm) with front fan only

GPU max length in MATX/ATX build

With rear GPU installed:

175/270 mm (direct): 314 mm length and 120 mm width in 3 slots (62 mm);

175/270 mm (direct): 325 mm length and 120 mm width in 3 slots (62 mm) with extra feet

With horizontal SFF GPU installed:

385/440 mm (female reverse): 332 mm length and 152 mm width in 4 slots (82mm)

385/440 mm (female reverse): 353 mm length and 152 mm width in 4 slots (82mm) with extra feet

GPU max length in MATX/ATX build with horizontal SFF GPU installed

Support MATX:

385/440 mm (female reverse): 239 mm length in 3 slots (61 mm)
